NO. |
Technical Parameter |
Type |
|||||
|
HBJS30 |
HBJS50 |
HBJS100 |
HBJS150 |
HBJS200 |
|||
|
1 |
Rated loading |
3000 Kg |
5000 Kg |
10000Kg |
15000Kg |
20000Kg |
|
|
2 |
Worktable size |
Φ800 mm |
φ1000 mm |
φ1000 mm |
φ1000 mm |
φ1100 mm |
|
|
3 |
Rotating angle |
n×360° |
|||||
|
4 |
Rotating height centre |
600～1600mm |
1000～1800mm |
||||
|
5 |
Rotating speed |
1rpm |
1rpm |
1rpm |
1rpm |
1rpm |
|
|
6 |
Rotating power |
1.5KW |
2.2kw |
3kw |
3kw |
2*1.5Kw |
|
|
7 |
Lifting speed |
500mm/min |
600mm/min |
||||
|
8 |
Lifting power |
2*1.5kw |
2*2.2kw |
2*2.2kw |
2*2.2kw |
2*2.2kw |
|
|
9 |
Travelling base |
Without |
|||||
|
10 |
Voltage |
380V-3PH-50HZ |
|||||
